FUZE PROFILE CW

FUZE.
ELATION Foco led FUZE PROFILE CW.

El Fuze Profile CW™ es un foco robotizado LED de tipo Recorte diseñado para ferias comerciales, escenarios, televisión, y una amplia variedad de eventos AV. Su fuente de 380 W (91 CRI ) garantiza una fiel reproducción del color a la vez que ofrece una potente salida de 11.000 lúmenes.Diseñado para iluminar tanto objetos de exposición como pancartas o personas clave con su campo plano y encuadre preciso, tiene muchas aplicaciones prácticas donde se requiera un foco de tipo elipsoidad totalmente automatizado. Una rueda de gobos rotatorios, dos ruedas de color con colores sólidos y filtros de corrección, además de iris rematan sus completas características.



CARACTERÍSTICAS
High Efficiency 380W White LED Engine, 91CRI
Dual Color Wheel (Solids and Color Corrections)
Rotating Gobo Wheel
Full Blackout Framing System
Iris and Frost
Wide Zoom Range from 9° to 43°

FUENTE
380W 6,000K White LED Engine
30,000 Hour Average LED Life*
*Lamp Life may vary depending on several factors including but not limited to:
Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control and Dimming.

DATOS FOTOMÉTRICOS
11,200 Total Lumen Output
CRI 91

Zoom Range 9° - 43°
Beam Angle 9.3° - 43.1°
Field Angle 10.3° - 46.8°

EFECTOS
Motorized Zoom
4 Rotating Full Blackout Framing Blades, +/- 60° Index
Variable Frost Filter
Motorized Iris
Variable 16-bit Dimming Curve Modes
High Speed Electronic Shutter and Strobe
Adjustable LED Refresh Rate Frequency

COLOR
2 Color Wheels
7 Solid Colors
7 Color Corrections and UV

GOBOS
1 Gobo Wheel
7 Rotating / Indexing Interchangeable Glass Gobos

CONTROL / CONEXIONES
2 DMX Channel Modes (26 / 40)
16-bit Pan, Tilt, and Dimming Control
Motorized Focus
DMX, RDM Protocol Support
4 Button Touch Control Panel
Full Color 180° Reversible LCD Menu Display
16 Bit Resolution Adjustable Movement
Hibernation Mode (Power Save)
5pin DMX In/Out
IP65 Locking Power Cable In/Out
With Wired Digital Communication Network

DIMENSIONES / PESO
Length: 408mm (15.9”)
Width: 252mm (9.9”)
Vertical Height: 698mm (27.4”)
Weight: 23.3kg (51.4 lbs.)

DATOS ELÉCTRICOS / TÉRMICOS
AC 100-240V - 50/60Hz
590W Max Power Consumption
-10°C to 45°C (14°F to 113°F)
BTU/hr (+/- 10%) 2011.9

ACTUALIZACIONES DE FIRMWARE
Current firmware can be found here (login required)
