FUZE SFX

FUZE.
ELATION Foco led FUZE SFX.

El FUZE SFX™ es un nuevo concepto de luminaria LED Spot de efectos, diseñada para una gran variedad de aplicaciones que requieren un foco polivalente compacto y potente. El SFX es capaz de proyectar desde fuertes haces a baños amplios utilizando un diseño óptico altamente eficiente al tiempo que proporciona más de 12.000 lúmenes de salida desde su fuente LED blanco de 300 W. Con 18 gobos cuidadosamente diseñados y un zoom de 4,5° a 38° , el FUZE SFX puede crear impresionantes efectos en el aire o proyecciones de imágenes precisas. El SFX permite lavados uniformes utilizando su filtro difusor al tiempo que ofrece una amplia gama de hermosos colores desde un sistema de mezcla CMY sumado a una rueda de colores. Los prismas dobles independientes giratorios y superpuestos, junto con un iris rápido rematan su completo conjunto de características.

Con una potencia verdaderamente notable y compacta para cualquier aplicación, el FUZE SFX garantiza la creación de efectos sorprendentes y proyecciones sobresalientes junto con lavados brillantes y hermosos en cualquier escenario.



CARACTERÍSTICAS
300W LED 6,600K White LED Engine
12,000 Total Lumen Fixture Output
Spot and Effects Fixture
Zoom Range from 4.5° to 38°
Variable CMY and 7-Position Color Wheel
High CRI and CTO filter
8 Rotating and 10 Fixed Gobos
Dual Independent Prisms for Layering
Motorized Iris
Variable Wash Frost Filter

ESPECIFICACIONES
FUENTE
300W 6,600K Bright White LED Engine
20,000 Hour Average LED Life*
*Lamp Life may vary depending on several factors including but not limited to:
Environmental Conditions, Power/Voltage, Usage Patterns (On-Off Cycling), Control and Dimming.

DATOS FOTOMÉTRICOS
12,135 Total Lumen Output
CRI 68+

Zoom Range 4.5° - 38°
Beam Angle 4.6° - 38.2°
Field Angle 5.6° - 42.2°

EFECTOS
Motorized Zoom
Remote Focus
Variable Frost Filter
Dual Independent Prisms (6 Facet linear &, 6 Facet round)
Motorized Iris
Variable 16-bit Dimming Curve Modes
High Speed Electronic Shutter and Strobe

COLOR
CMY Variable Color Mix
7 Position Color Wheel
High CRI Filter, CRI 84
CTO Filter (with High CRI Filter), 3200K, CRI 77

GOBOS
2 Gobo Wheels
Wheel #1 with 8 Rotating / Interchangeable Glass Gobos
Wheel #2 with 10 Static Gobos

CONTROL / CONEXIONES
31 DMX Channels
16-bit Pan, Tilt, and Dimming Control
DMX Adjustable LED Frequency
DMX, RDM, E-FLY Wireless, Art-Net, sACN Protocol Support
4 Button Touch Control Panel
Full Color 180° Reversible LCD Menu Display
Locking 5pin XLR Connector In/Out
Locking RJ45 Ethernet Connector In/Out
IP65 Locking Power Connector In/Out
USB Connection (Firmware Updates)
With Wired Digital Communication Network

DIMENSIONES / PESO
Length: 362mm (14.3”)
Width: 233mm (9.2"")
Vertical Height: 595mm (23.4"")
Weight: 19.3kg (46.3 lbs.)

DATOS ELÉCTRICOS / TÉRMICOS
AC 100-240V - 50/60Hz
432W Max Power Consumption
-10°C to 45°C (14°F to 113°F)
BTU/hr (+/- 10%) 1473.12

ACTUALIZACIONES DE FIRMWARE
Current firmware can be found here (login required)
